+12V: 62.5 A (750 W)
, +3.3V: 20 A
, +5V: 20 A
, +5VSB: 3 A (15 W)
, -12V: 0.3 A (3.6 W)
, 16-pin PCI Express 5.0 Connector: 1
, 24-pin Main Connector: 1
, 4/8-pin +12V Power Connector: 2
, 4-pin Peripheral Power Connector: 4
, 6/8-pin PCI Express Connector: 4
, 80 Plus Certification: 80 Plus Gold
, Box Weight Brutto (kg): 12.5 kg
, Built-in Devices: Power Button
, Circuit Protection: Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power
, Depth (mm): 140 mm
, EAN Code: 4710679816821
, Efficiency: 89%
, Fan Diameter: 120 mm
, Fans Installed Quantity: 1
, Form Factor: ATX
, Height (mm): 86 mm
, Input Frequency: 47/63 Hz
, Input Power Connectors Quantity: 1
, Input Power Connectors Type: IEC-320 C14
, Input Voltage: AC 90-264 V
, Maximum Operating Ambient Temperature: 50 °C
, Maximum Output Power: 750 W
, Mean Time Between Failures: 100000 hr
, Minimum Operating Ambient Temperature: 0 °C
, Nominal Weight: 2.08 kg
, Pack Weight Brutto (kg): 2.5 kg
, Pack Weight Netto (kg): 2.37 kg
, Package Type: Retail
, Packs in Box: 5
, Pieces in pack: 1
, Power Adapter and Power Supply Features: Active PFCLow noise
, Power Device Location: Plug-in-module
, Power Device Type: Power Supply
, Retail Packaging Net Weight Carton: 0.1 kg
, Retail Packaging Net Weight Plastic: 0.3 kg
, S-ATA Connector: 8
, Warranty Products Returnable: Yes
, Warranty Term (month): 60 month(s)
, Warranty validation Criteria: Serial Number
, Width (mm): 150 mm
